Higher Product Flexibility
Wide range of width, flange thickness and web thickness combinations for any nominal depth.
Parallel Flange Sections & Conventional Structurals — sourced directly from SAIL.
Structurally Ahead
Parallel Flange Sections are hot rolled steel structural sections with parallel flanges having square toes and curves at the root of flange and web.
ABOUT THE PRODUCT
Parallel Flange Sections are hot rolled steel structural sections, with parallel flanges having square toes and curves at the root of flange and web.
Parallel Flange Sections meet international standards of quality and stringent requirements of the infrastructure and construction industries.
KEY BENEFITS
Wide range of width, flange thickness and web thickness combinations for any nominal depth.
Higher bending strength for beams and higher axial load carrying capacity for columns.
Greater radius of gyration lowers slenderness ratio and allows withstanding of buckling to a greater extent.
Higher strength-to-weight ratio leads to lighter structures and foundations.
TECHNICAL DATA
STRUCTURAL EXAMPLE
Floor beams
100 kg/mRoof beams
Lower level floor beams
600 kg/m²Mid level floor
200 kg/mRoof beams
On each column in both X & Z direction
EFFICIENCY
| Section | Weight in Tons |
|---|---|
| MB 600 x 123.0 | 5.79 |
| MB 450 x 72.4 | 1.735 |
| MB 350 x 52.4 | 1.254 |
| MB 250 x 37.3 | 1.125 |
| Total | 9.904 |
| Section | Weight in Tons |
|---|---|
| WPB 240 x 83.20 | 3.985 |
| WPB 400 x 66.31 | 1.588 |
| WPB 300 x 49.32 | 1.181 |
| NPB 250 x 30.11 | 0.906 |
| Total | 7.661 |
HIGH TENSILE SECTIONS
ELECTRIC POLE APPLICATION
| Section | Mass (Kg/m) |
Sectional Area (cm²) |
D (Depth) |
B (Width) |
t (Web thick) |
T (Flange thick) |
Flange Slope a deg |
R₁ (Root Radius) |
R₂ |
|---|---|---|---|---|---|---|---|---|---|
| WPB 160 | 30.44 | 38.78 | 152 | 160 | 6 | 9 | - | 15 | - |
| Section | Mass (Kg/m) |
Ix (cm⁴) |
Iy (cm⁴) |
Rx (cm) |
Ry (cm) |
Zx (cm³) |
Zy (cm³) |
Zpx (cm³) |
Zpy (cm³) |
|---|---|---|---|---|---|---|---|---|---|
| WPB 160x160 | 30.44 | 1670 | 615 | 6.56 | 3.98 | 220 | 76.9 | 245 | 117 |
FABRICATION & ECONOMY
Easier connection of joints by direct bolting on flanges without using tapered washes and easier butt welding of plate at edge of flange.
Substantial saving in material weight when used as compression member (columns) or flexural member (beams).
| Type | Size | Weight Kg/m | Area (Sq.cm.) | Radius of Gyration (cm.) |
|---|---|---|---|---|
| ISMB | 600x210 | 121.00 | 154 | 4.08 |
| NPB | 600x220 | 122.45 | 155 | 4.66 |
| WPB | 400x300 | 124.80 | 158 | 7.33 |
| Section | Mass (Kg/m) | Section Modulus about major axis (cm³) |
|---|---|---|
| MB 400 | 61.55 | 1020 |
| NPB 400x180x57.38 | 57.38 | 1020 |
STRUCTURAL PERFORMANCE
NEX Parallel Flange Sections are more efficient and provide more economic designs.
Contact Bansal Steel Traders for NEX Parallel Flange Sections and structural steel requirements.
